CE Certified 270nm 265nm 275nm UVC LED Chip with Quartz Glass Lens for Water Purifier

Large Image : CE Certified 270nm 265nm 275nm UVC LED Chip with Quartz Glass Lens for Water Purifier

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Learnew

Payment & Shipping Terms:

Minimum Order Quantity:	5000

Contact Now

CE Certified 270nm 265nm 275nm UVC LED Chip with Quartz Glass Lens for Water Purifier

Description

Chip Material:	Ingan	Input Voltage:	5-7V
Lifespan:	10000 Hours	Operating Temperature:	-20 - 65℃
Power:	1W	Power Dissipation:	0.4
Product Weight:	0.05 Kg	Storage Temperature:	-40 - 110℃
Viewing Angle:	120°	Wavelength:	250-280nm
Whole Size:	3.5*3.5mm	Optical Power:	15-20mW
Forward Current:	100mA (max=150mA)	Lens Material:	Quartz Glass Lens
Chip Size:	4.5mil*4.5mil
Highlight:	270nm UVC LED Chip , 265nm UVC LED Chip , 275nm UVC LED Chip

Best Quality CE Certified UV UVC LED 3535 - 270nm/265nm/275nm/280nm SMD LED Epistar Chip for Water Purifier

Product Specifications

Parameter	Value
IF	100mA (max=150mA)
Substrate	ALN Coppering
Whole Size	3.5*3.5mm
Lens	Quartz Glass Lens
Life Span	LM70=5000Hrs LM50=10000Hrs
Radiant Irradiance	80-120mW/cm²
Junction Temperature	60°C
View Angle	120°
