0.5W UVC LED CHIP Specification
| UV-C |
POWER |
Dominant Wavelength |
Optical Power |
IF |
VF |
WHOLE SIZE |
VIEW ANGLE |
LENS |
SUBSTRATE |
Life span |
JUNCTION TEMPERATURE |
| LN-SMD3535UVC-P0.5D |
0.5W |
265-285nm |
6-8mW |
40mA
(max=50mA) |
5-7V |
3.5*3.5MM |
120° |
QUARTZ GLASS LENS |
ALN Coppering |
LM70=3000Hrs
LM50=6000Hrs |
60C |
| LN-SMD3535UVAC-P0.5 |
0.5W |
265-285nm
(Sterilization) |
6-8mW |
50mA
(max=60mA) |
5-7V |
3.5*3.5MM |
120° |
QUARTZ GLASS LENS |
ALN Coppering |
60C |
395-405nm
(Assist) |
20-40mW |
50mA
(max=60mA) |
3.0-3.6V |
| LN-SMD3535UVAC-P0.5L |
0.5W |
265-285nm
(Sterilization) |
4-6mW |
50mA |
5-7V |
3.5*3.5MM |
120° |
QUARTZ GLASS LENS |
ALN Coppering |
LM70=2000Hrs
LM50=5000Hrs |
60C |
395-405nm
(Assist) |
50-70mW |
3.0-3.6V |
Application
- ICU Hospital
- Air purifier
- Water purifier
- Washing machines
- Sterilization...
Design Advantage
- Quartz glass package
- High radiant flux
- Narrow Wavelength
- Inorganic & Nitrogen package
- Low thermal resistance
