3535 UVB LED CHIP Specification
| UV-B |
POWER |
Dominant Wavelength |
Optical Power |
IF |
VF |
WHOLE SIZE |
VIEW ANGLE |
LENS |
SUBSTRATE |
JUNCTION TEMPERATURE |
Design Advantage |
| LN-SMD3535UVB-P1 |
1W |
290-300nm |
14-18mW |
100mA
(Max=150mA) |
5-7V |
3.5*3.5MM |
120° |
QUARTZ GLASS LENS |
ALN Coppering |
60-80C |
1,Quartz glass package
2,High radiant flux
3,Narrow Wavelength
4,Inorganic & Nitrogen package
5,Low thermal resistance |
| 300-306nm |
| 306-310nm |
| 310-315nm |
| LN-SMD3535UVB-P1Z |
1W |
290-300nm |
15-20mW |
100mA
(Max=150mA) |
| 300-310nm |
| 310-320nm |
| LN-SMD3535UVB-P1D |
1W |
290-300nm |
10-14mW |
100mA |
| 300-306nm |
| 306-310nm |
| 310-315nm |
| LN-SMD3535UVB-P0.5 |
0.5W |
290-300nm |
4-7mW |
50mA
(Max=60mA) |
| 300-306nm |
| 306-310nm |
| 310-315nm |
Application
- Medical treatment
- Animal calcium supplement
- Plant growth hormone supplement
Design Advantage
- Quartz glass package
- High radiant flux
- Narrow Wavelength
- Inorganic & Nitrogen package
- Low thermal resistance
