3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment

3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment
3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment
3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment

Large Image :  3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment

Product Details:
Place of Origin: China
Brand Name: Learnew Opto
Certification: RoHS
Model Number: LN-SMD3535UVB-P1/LN-SMD3535UVB-P1A/LN-SMD3535UVB-P1D/LN-SMD3535UVB-P0.5
Payment & Shipping Terms:
Minimum Order Quantity: 1000
Price: Negotiable
Packaging Details: Anti-static Blister Packing
Delivery Time: 15-45 working days
Payment Terms: L/C, T/T
Supply Ability: 99999pcs

3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment

Description
Item: UVB LED Chips POWER: 0.5W 1W
Dominant Wavelength: 290-315NM Optical Power: 15-20mW
IF: 100mA (Max=150mA) VF: 5-7V
WHOLE SIZE: 3.5*3.5MM VIEW ANGLE: 120°
LENS: QUARTZ GLASS LENS SUBSTRATE: ALN Coppering
Life Span: LM70=5000Hrs LM50=10000Hrs JUNCTION TEMPERATURE: 60C
Highlight:

3535 UVB LED Chips

,

UVB LED Chips For Medical Treatment

UVB LED Chips 3535 0.5W-1W narrow wavelength 290-315nm QUARTZ GLASS LENS 120° UVB LED chips for Medical treatment

0.5W-1W UVB LED CHIPS PARAMETERS

UV-B POWER Dominant Wavelength Optical Power IF VF WHOLE SIZE VIEW ANGLE LENS SUBSTRATE JUNCTION TEMPERATURE
LN-SMD3535UVB-P1 1W 290-300nm 14-18mW 100mA
(Max=150mA)
5-7V 3.5*3.5MM 120° QUARTZ GLASS LENS ALN Coppering 60-80C
300-306nm
306-310nm
310-315nm
LN-SMD3535UVB-P1A 1W 290-300nm 15-20mW 100mA
(Max=150mA)
300-310nm
310-320nm
LN-SMD3535UVB-P1D 1W 290-300nm 10-14mW 100mA
300-306nm
306-310nm
310-315nm
LN-SMD3535UVB-P0.5 0.5W 290-300nm 4-7mW 50mA
(Max=60mA)
300-306nm
306-310nm
310-315nm



UVB LED Chips Design Advantage

1,Quartz glass package
2,High radiant flux
3,Narrow Wavelength
4,Inorganic & Nitrogen package
5,Low thermal resistance



UVB CHIPS Appilcation

1.Marijuana refinement

2.Animal calcium supplement
3.Medical treatment
4.Plant growth hormone supplement



3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 0

3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 1

3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 2

3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 3







3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment 4
