Product Details:
|
Product Name: | UVB LED Chip | POWER: | 1W/0.5W |
---|---|---|---|
VF: | 5-7V | WHOLE SIZE: | 3.5*3.5MM |
VIEW ANGLE: | 120° | JUNCTION TEMPERATURE: | 60-80CUV-B POWER PICTURE Dominant Wavelength Optical Power IF VF WHOLE SIZE VIEW ANGLE LENS SUBSTRATE JUNCTION TEMPERATURE Design Advantage Application CHIPS "Qty< 5KPCS" "Qty>= 5KPCS" "Qty>= 20KPCS" "Qty>= 50KPCS" LN-SMD3535UVB-P1 1W 290-300nm 14-18mW " |
High Light: | 7V UVB Led Chip,ALN Coppering UV Led Modules,SMD 3535 UV Led Chip |
LEAENEW OEM ODM FACTORY LED 3535 UVB 0.5W CHIP 310NM 305NM 320NM 325NM 340NM 350NM LED diode for therapy treatment light
310nm uvb led Product specification
UV-B | POWER | Dominant Wavelength | Optical Power | IF | WHOLE SIZE | LENS | SUBSTRATE | JUNCTION TEMPERATURE |
LN-SMD3535UVB-P1 | 1W | 290-300nm | 14-18mW | 100mA (Max=150mA) |
3.5*3.5MM | QUARTZ GLASS LENS | ALN Coppering | 60-80C |
300-306nm | ||||||||
306-310nm | ||||||||
310-315nm | ||||||||
LN-SMD3535UVB-P1D | 1W | 290-300nm | 10-14mW | 100mA | ||||
300-306nm | ||||||||
306-310nm | ||||||||
310-315nm | ||||||||
LN-SMD3535UVB-P0.5 | 0.5W | 290-300nm | 4-7mW | 50mA (Max=60mA) |
||||
300-306nm | ||||||||
306-310nm | ||||||||
310-315nm |
UVB chip Design Advantage
3535 UVB LED Application
295nm uvb led FAQ
Q1: Do you supply OEM,ODM service?
A1: YES,absolutely it can be realized.Learnew focus on OEM & ODM service more than 7 years.
Q2:All the pictures are real photo?
