0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens
0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens
0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens

Large Image :  0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens

Product Details:
Place of Origin: CHINA
Brand Name: LEARNEW
Certification: CE RoHS SGS
Model Number: LN-SMD3535UVC-P0.5
Payment & Shipping Terms:
Minimum Order Quantity: 1000
Price: USD0.8-2.0/PCS
Packaging Details: Anti-static Blister packing
Delivery Time: 7-12 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 800,000PCS per month

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens

Description
Peak Wavelength: 250-260nm/260-270nm/270-280nm Input Current: 40-60mA
Size: 3.5*3.5mm Optical Power: 4-6mW
View Angle: 120DEG Package Model: Flip Chip
Electrical Power: 0.5W Input Voltage: 6.0-8.0V
Highlight:

0.5W 260nm UVC LED Diode

,

50ma 6mw SMD UVC LED

,

255nm 260nm UVC LED Diode

uvc led price high power uv led germicidal diode 255nm 260nm 265nm 275nm 0.5w 3535 6-8v 50ma 4-6mw smd uvc led

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 0

models LN-SMD3535UVC-P0.5(255nm) LN-SMD3535UVC-P0.5(265nm) LN-SMD3535UVC-P0.5(275nm)
Electronic power 0.5W 0.5W 0.5W
Peak wavelength 250-260nm 260-270nm

270-280nm

Radiant power 4-6mW 4-6mW 4-6mW
Working current 40-60mA 40-60mA 40-60mA
Working voltage 6.0-8.0V 6.0-8.0V 6.0-8.0V
Circuit 1S1P 1S1P 1S1P
Packing technology

New Generation Flip chip

PW/LG/Dowa/Seoul semi

New Generation Flip chip

PW/LG/Dowa/Seoul semi

New Generation Flip chip PW/LG/Dowa/Seoul semi
LED Diode size 3.5*3.5mm 3.5*3.5mm 3.5*3.5mm
LENS Quartz Glass Quartz Glass Quartz Glass
View angle 120DEG 120DEG 120DEG
Substrate design ALN coppering ALN coppering ALN coppering
Thermal resistance 0.1-0.2C/W 0.1-0.2C/W 0.1-0.2C/W
Life span(LM50) 10,000 hrs 10,000 hrs 10,000 hrs





































0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 1



0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 2

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 3

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 4

  • Long life span,LM70>=5000 hrs and LM50>=10,000 hrs.
  • Certifications
  • High radiant flux
  • Low thermal resistance
  • Ingorganic encapsulation and Quartz Glass package

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 5

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 6

0.5W 255nm 260nm UVC LED Diode 50ma 6mw SMD UVC LED Quartz Glass Lens 7

Q: What technical support can I get after purchase?

A: Data sheet and PDF will be provided to dear you. Our sales engineer will be answering your questions any time.



Q: If there is LED failure, how can you support?

A: Clients provide us with pictures of the failed products or the samples rejected And give a test report, our engineers of after sale team will analyze the failure reasons. If the failure was caused by Learnew, we will compensate with qualified replacement as fast as we could!



Q: Would you offer free samples?

A: Yes. For our factory to produce conventional white light products, we will provide 2pcs. The sample cost of other custom designed products will be deducted from the customer's subsequent orders.



Q: Are you manufacturer or trade company?

A: In worldwide market, Learnew is well know as an experienced and professional LED manufacturer.



Q: What about the lead time?

A: It depends on the order quantity. Generally the lead time should be 7-12 working days.



Q: What payment method do you accept?

A: We accept T/T, Paypal, Western Union and others more as clients’ requirements.



Q: How can I get a quotation from you?

A: Please kindly leave us messages about your needs,including products and quantity.Our professional sales team will reply you within minutes/hours.
