7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light

Certification
China Shenzhen Learnew Optoelectronics Technology Co., Ltd. certification
China Shenzhen Learnew Optoelectronics Technology Co., Ltd. certification
Customer Reviews
August 25, 2023, I purchased UVA LED chips from Learnew. Learnew delivered the custom UVA chips we requested quickly and with excellent workmanship. It was a pleasure to work with Learnew. He was able to tell me exactly which product would work with my curing printer, saving me a lot of time. They are very professional.

—— Ashraf Trading

October 13, 2023,I received a customized 3535 COB LED Chip .Their attention to detail, timely responses, and on-time delivery have exceeded my expectation.The sample I received is what I need, very bright, I will choose LEARNEW for a long time in the future

—— Hector Bustillo

March 2024,Just received the product and have tried it,The design of these Hight LED chips is outstanding. They are compact, easy to install, and provide excellent illumination. I am extremely satisfied with their performance!

—— Fabio Antista

I am thoroughly impressed with the functionality of these UV LED chips. They offer reliable UV output, high efficiency, and a long lifespan. A great investment for any UV application!

—— Ali Muhammad

I'm Online Chat Now

7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light

7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light
7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light
7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light 7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light

Large Image :  7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light

Product Details:
Place of Origin: CHINA
Brand Name: LEARNEW
Certification: CE RoHS SGS
Model Number: LN-CAS14SR-P7-11/LN-CAS14SG-P7-11/LN-CAS14SB-P7-11
Payment & Shipping Terms:
Minimum Order Quantity: 5000-10000
Price: Negotiable price
Packaging Details: Anti-static Blister packing
Delivery Time: 7-12 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200,000PCS per month

7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light

Description
POWER: 5W View Angle: 120°
CCT: RED=620-630nm;GREEN=520-530nm;BLUE=460-470nm; LUMINUOUS EFF: 40-60lm/w/90-110lm/w/20-30lm/w
VF: 14-17V/21-24V/21-24V IF: 300mA
CIRCUIT: 7S2P WHOLE SIZE: 14*14mm
Highlight:

14*14mm EPISTAR COB LED

,

7W RGB COB LED Chip

,

14*14mm RGB COB LED Chip

7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light 0
7W 1414 series RGB led cob chips EPISTAR OR EPILED chip led cob for led bulb light


Models LN-CAS14SR-P7-11 LN-CAS14SG-P7-11 LN-CAS14SB-P7-11
POWER 7W 7W 7W
CCT

RED=620-630nm

GREEN=520-530nm BLUE=460-470nm
LUMINUOUS EFF 40-60lm/w 90-110lm/w 20-30lm/w
IF 300mA 300mA 300mA
VF 14-17V 21-24V 21-24V
CIRCUIT 7S2P 7S2P 7S2P
WHOLE SIZE 14*14mm 14*14mm 14*14mm
LES R11mm R11mm R11mm
VIEW ANGLE 120° 120° 120°
SUBSTRATE MIRROR ALU MIRROR ALU MIRROR ALU

7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light 1

Design Advantage:



1, High efficiency

2, Free circuit

3, Long life span

4, 2.5-5.0nm pure wavelength range

5, Color constancy

6, Gold wire bond

7, CLS-A standard Chip

8, Life decay less than 3% in 3000Hrs

9, High performance in electrical property

10, No glare & Eyes protect

11, Super power available



 7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light 2




7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light 3
1, 6 Engineers with 5-10 years LED industry experience for any technology and customized products support.
2, Learnew brand oversea
3, 8-10 full automatic production lines
4, Middle-sized Lab test centre
5, Over 5 years oversea sales team
6, 2000 sqm production centre
7, OEM & ODM









7W RGB COB LED Chip 14*14mm EPISTAR COB LED For Led Bulb Light 4
Q1: Do you supply OEM,ODM service?
A1: YES,absolutely it can be realized.

Q2: All the pictures are real photo?
A2: Yes, the pictures of all products on this page are 100% real shoot by us.

Q3: How can I get a quotation from you?
A3: Please kindly leave us messages about your needs,including products and quantity,our professional team will reply you very soon (mostly within few hours).

Q4: Is there any discount for bulk order?
A4: Yes, if you need bulk order or you want customized products, we can provide wholesale price.

Q5: Do you support drop shipping and how much is the shippping cost?
A5: Yes, we support drop shipping. You should leave the receiver's information when you place the order, then we will send the goods according the address you have left. The shipping cost are based on your order's volume and weight, and it can be calculated.

Q6: How to place an order?
A6: If you want to place an order, Please feel free to send us an inquiry email or contact us by trademanager online, we will reply you within 24hours(working day).
