High Voltage SMD 7030 LED , Led Smd 7030 450 - 460 Nm Light Sanan Chip

China High Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan Chip supplier
High Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan Chip supplier High Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan Chip supplier

Large Image :  High Voltage SMD 7030 LED , Led Smd 7030 450 - 460 Nm Light Sanan Chip

Product Details:

Place of Origin: SHENZHEN
Brand Name: Yuanke
Certification: CE.SGS.ROHS
Model Number: YKHV7030B1

Payment & Shipping Terms:

Minimum Order Quantity: 8K
Price: Please inquiry
Packaging Details: 4000pcs/Reel our product package size is 25x23CM, and is the use of aluminum vacuum packaging. And different types of containers, small cartons can be installed about 100K products. Large box can hold about 500K.
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Contact Now
Detailed Product Description
Type: SMD LED Chip Material: InGaN
Emitting Color: Blue Luminous Intensity: Customers' Requirements
Luminous Flux(lm): 25-30LM Power: 1W
Viewing Angle(°): 120 Degree Color Rendering Index: Null
Color Temperature: 450-460NM Operating Temperature: -20 - 85
Chip Brand: Epistar Chip, Sanan Chip,Epileds Chip Current: 150mA
Voltage: 6-7V Warranty: 2years
Lifespan: 50000-100000Hours

High voltage 6v 1w power smd 7030 led blue color with 450-460nm light sanan chip



Features:

  • PLCC-2 package.
  • High power LED type.
  • White package.
  • Optical indicator.
  • Colorless clear window.
  • Ideal for backlight and light pipe application.
  • Inter reflector.
  • Wide viewing angle.
  • Very long operating life.
  • Instant light (less than 100 ns).
  • Reading lights (car, bus, aircraft).
  • Mini_ accent/Up lighters/Down lighters/Orientation.
  • Bollards/Security/Garden.
  • Cove/Under shelf/Task.
  • Automotive rear combination lamps.
  • Indoor/Outdoor Commercial and Residential Architectural.
  • Edge_ lit signs (Exit, point of sale).
  • LCD Backlights/Light Guides.
  • Designed for high current operation.
  • Low thermal resistance.
  • Suitable for automatic placement equipment.
  • Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
  • The product itself will remain within RoHS compliant Version.



Applications:

  • Horticultural operations
  • Commercial vegetable and flower production
  • Supplemental greenhouse lighting
  • Hydroponics
  • Research experiment

Notes:

  • All dimensions are in millimeters.
  • Tolerance is ± 0.10mm (.004″) unless otherwise noted.

Specifications are subject to change without notice.

Part No. Chip Material Lens Color Source Color
YKHV7030B1 AlGaInP Water Clear Blue














Product Description
Package Dimensions
                      High Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan Chip
Recommended Soldering Patter
                                         High Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan Chip
SURFACE MOUNT LED LAMPS
Product Type:YKHV7030B1
Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Value Unit
Forward current
If
150 mA
Reverse voltage Vr -- V
Power dissipation Pd 960 MW
Operating temperature range Top -25~+80 °C
Storage temperature range Tstg -30~+85 °C
Peak pulsing current(1/8 duty f=1KHz) Ifp 200 mA
Junction Temperature Tj 115 ℃/W
Electrostatic Discharge(HBM) ESD 1000 V
Electro-Optical characteristics (TA=25°C)



Parameter

Test

Condition



Symbol



Color

Value Unit
Min Typ Max



Color Temperature

IF=150mA CCT B -- -- -- K



Forward voltage

IF=150mA Vf B 6 -- 7 V



luminous flux

IF=150mA φ B 25 -- 30 LM



Viewing angle at 50% IV

IF=150mA 2θ1/2 B -- 120 -- Deg



Dominant wavelength

IF=150mA λd -- 450 -- 460 nm



Reverse current

Vr=5V Ir B -- -- -- μA



Color Rendering Index

IF=150mA CRI -- -- -- -- Ra



Reel Dimensions:
0.80mm Height Top View White LED SMD Chip Promotion 3014 6000 -7500K


Carrier Tape Dimensions:
Loaded quantity 4000 PCS Per reel.

High Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan ChipHigh Voltage SMD 7030 LED , Led Smd 7030  450 - 460 Nm Light Sanan Chip


We provide EMS DHL UPS FedEx TNT that several different types of express allows you to select, under normal circumstances, the transport time is in 5 to 10 days or so, if large cargo, go shipping, so time is longer, but safer, and the freight is lower.



  • Why choose YUANKE led chip ?

1. Well-known chip material

2. 99.99% gold wire bonding

3. 2 years warranty

4. Over 10 years work experience technical service team

5. 24 hours service Professional sales team

6. Free Sample is available

7. Fast delivery

8.100% QC inspection Before Shippment

9. Aiming at the consult of "high quality, zero defect”, give you the best quality, best service.


FAQ



Q1. Can I have a sample order?



A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable .free samples will be available.



Q2: What’s the delivery time?



A: It usually takes about 5-7 days to produce an order. But the exact delivery time might be different for different orders or at different time.



Q3:What's your warranty terms?



A: The warranty for all our Led products is 2 years.



Q4: How does your factory do regarding quality control?



A: Quality is priority.We always believe Quality is our marketing and attach great importance to quality control from the very beginning to the end of the production.

Every product will be fully assembled and carefully tested before it's packed for shipment.
