PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current

China PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current supplier
PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current supplier PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current supplier PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current supplier

Large Image :  PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current

Product Details:

Place of Origin: SHENZHEN
Brand Name: Yuanke
Certification: CE.SGS.ROHS
Model Number: YKFHP5050RGBW4W

Payment & Shipping Terms:

Minimum Order Quantity: 1K
Price: Please inquiry
Packaging Details: 1000pcs/box our product package size is 25x23CM, and is the use of aluminum vacuum packaging. And different types of containers, small cartons can be installed about 100K products. Large box can hold about 500K.
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Contact Now
Detailed Product Description
Type: SMD LED Chip Material: InGaN
Emitting Color: RGBW Luminous Intensity: Customers' Requirements
Luminous Flux(lm): High Brightness Power: 4 Watts
Viewing Angle(°): 120 Degree Color Rendering Index: 70
Color Temperature: RGB+6000-7000K Operating Temperature: -20 - 85
Chip Brand: Epistar Chip, Sanan Chip,Epileds Chip Current: 1200mA
Voltage: R:2.0-2.4V G/B/W:3.0-3.4V Warranty: 2 Years
Lifespan: 50000-100000H

PLCC8 High Power 8 Pin SMD LED 4W - 12W RGBW LED Diode Chip LED



Features:

  1. Small package with high efficiency
  2. Long operating life.
  3. Available in white, green, blue, red, yellow, Amber
  4. View angle: 120°.
  5. Low voltage DC operated.
  6. The product itself will remain within RoHS compliant Version.
  7. ESD protection.



Applications:

  1. Reading lights (car, bus, aircraft).
  2. Portable (flashlight, bicycle).
  3. Mini_accent/Uplighters/Downlighters/Orientation.
  4. Bollards/Security/Garden.
  5. Cove/Undershelf/Task.
  6. Automotive rear combination lamps.
  7. Traffic signaling/Beacons/ Rail crossing and Wayside.
  8. Indoor/Outdoor Commercial and Residential Architectural.
  9. Edge_lit signs (Exit, point of sale).
  10. LCD Backlights/Light Guides.

Recommended Solder Pad Design

PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current

PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current

Absolute Maximum Rating @ Ta=25°C



Parameter Symbol Maximum Rating   Unit

Continuous Forward Current IF 350   mA

Peak Forward Current IFp 500   mA
(1/10 Duty Cycle, 0.1ms Pulse Width)


Reverse Voltage VR 5   V

Power Dissipation PD 4   W

Electrostatic discharge ESD 1000   V

Operating Temperature Range TOPR -25°C to +85°C

Storage Temperature Range TSTG -35°C to +105°C

Lead Soldering Temperature TSOL 360°C
(3mm from tne base of the epoxy bulb)







Electrical / Optical Characteristic @ Ta=25°C



Parameter Symbol Color Min. Typ. Max. Unit Test Condition

    G 3.0 3.2 3.4 V IF=350mA

Forward Voltage VF B/ W 3.0 3.2 3.4 V IF=350mA

    R 2.2 2.3 2.4 V IF=350mA

    G 80 90 100 Lm IF=350mA

Luminous Flux Φ B /W 20/100 25/110 30/120 Lm IF=350mA

    R 30 40 50 Lm IF=350mA

    G 520 522.5 525 nm IF=350mA

Dominant Wavelength Wld B 460 462.5 465 nm IF=350mA

    R 620 622.5 625 nm IF=350mA

Color Temperature Tc W 6000 7000 8000 K IF=350mA

Reverse Current IR       10 μA VR=5V

Viewing Angle 2θ1/2       120 deg IF=350mA

Recommend Forward Current IF(rec) RGBW     350 mA





     PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current

PLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA CurrentPLCC8 High Power 8 Pin SMD LED 4w , Rgbw Led Diode 1200 MA Current



We provide EMS DHL UPS FedEx TNT that several different types of express allows you to select, under normal circumstances, the transport time is in 5 to 10 days or so, if large cargo, go shipping, so time is longer, but safer, and the freight is lower.



Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.







FAQ



Q1. Can I have a sample order?



A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable .free samples will be available.



Q2: What’s the delivery time?



A: It usually takes about 5-7 days to produce an order. But the exact delivery time might be different for different orders or at different time.



Q3:What's your warranty terms?



A: The warranty for all our Led products is 2 years.



Q4: How does your factory do regarding quality control?



A: Quality is priority.We always believe Quality is our marketing and attach great importance to quality control from the very beginning to the end of the production.

Every product will be fully assembled and carefully tested before it's packed for shipment.
