Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal

China Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal supplier
Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal supplier Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal supplier

Large Image :  Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal

Product Details:

Place of Origin: SHENZHEN
Brand Name: Yuanke
Certification: CE.SGS.ROHS
Model Number: YK3014Y

Payment & Shipping Terms:

Minimum Order Quantity: 8K
Price: Please inquiry
Packaging Details: 4000pcs/Reel our product package size is 25x23CM, and is the use of aluminum vacuum packaging. And different types of containers, small cartons can be installed about 100K products. Large box can hold about 500K.
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Contact Now
Detailed Product Description
Type: SMD LED Chip Material: InGaN
Emitting Color: Yellow Luminous Intensity: Customers' Requirements
Luminous Flux(lm): 600-800mcd Power: 0.1 Watts
Viewing Angle(°): 120 Degree Color Rendering Index: Null
Color Temperature: 590-592nm Operating Temperature: -20 - 85
Chip Brand: Epistar Chip, Sanan Chip,Epileds Chip Current: 30mA
Voltage: 2.0-2.4V Warranty: 2 Years
Lifespan: 50000-100000H

3014 smd led 0.1w Yellow orange 585nm 590nm 595nm high brightness Copper bracket for Led car turn signal



Product Description

Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal
Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal


Product features:


1.High Lumens Output & Low Brightness Decay
2.Stable Performance & Great CCT Inity.
3.Wid Color Temperature Range

Product quality:

1. First-Choice for Indoor Ligting
2. Good raw materials
3. Copper layer
4. 99.99% Gold wire connection

5.San'an epistar chips
6. Lifespan is >50 000 hours easily

SURFACE MOUNT LED LAMPS
Product Type:YK3014Y
Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Value Unit
Forward current
If
30 mA
Reverse voltage Vr 5 V
Power dissipation Pd 100 MW
Operating temperature range Top -25~+80 °C
Storage temperature range Tstg -30~+85 °C
Peak pulsing current(1/8 duty f=1KHz) Ifp 50 mA
Junction Temperature Tj 115 ℃/W
Electrostatic Discharge(HBM) ESD 1000 V
Electro-Optical characteristics (TA=25°C)



Parameter

Test

Condition



Symbol



Color

Value Unit
Min Typ Max



Color Temperature

IF=30mA CCT Y -- -- -- K



Forward voltage

IF=30mA Vf Y 2.0 -- 2.4 V



luminous flux

IF=30mA φ Y 600 -- 800 MCD



Viewing angle at 50% IV

IF=30mA 2θ1/2 Y -- 120 -- Deg



Dominant wavelength

IF=30mA λd -- 590 -- 595 nm



Reverse current

Vr=5V Ir Y -- 5 -- μA



Color Rendering Index

IF=30mA CRI -- -- -- -- Ra



Reel Dimensions:



Carrier Tape Dimensions:

Loaded quantity 4000 PCS Per reel.

Yellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn SignalYellow Orange 3014 SMD LED 585nm / 590nm / 595nm For Led Car Turn Signal





Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.




We provide EMS DHL UPS FedEx TNT that several different types of express allows you to select, under normal circumstances, the transport time is in 5 to 10 days or so, if large cargo, go shipping, so time is longer, but safer, and the freight is lower.



FAQ



Q1. Can I have a sample order?



A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable .free samples will be available.



Q2: What’s the delivery time?



A: It usually takes about 5-7 days to produce an order. But the exact delivery time might be different for different orders or at different time.



Q3:What's your warranty terms?



A: The warranty for all our Led products is 2 years.



Q4: How does your factory do regarding quality control?



A: Quality is priority.We always believe Quality is our marketing and attach great importance to quality control from the very beginning to the end of the production.

Every product will be fully assembled and carefully tested before it's packed for shipment.
