0.2 W Green Smd 5050 Led Chips 15 - 20 LM Luminous Flux Long Life Span

China 0.2 W Green Smd 5050 Led Chips 15 - 20 LM Luminous Flux Long Life Span supplier
0.2 W Green Smd 5050 Led Chips 15 - 20 LM Luminous Flux Long Life Span supplier 0.2 W Green Smd 5050 Led Chips 15 - 20 LM Luminous Flux Long Life Span supplier

Large Image :  0.2 W Green Smd 5050 Led Chips 15 - 20 LM Luminous Flux Long Life Span

Product Details:

Place of Origin: SHENZHEN
Brand Name: Yuanke
Certification: CE.SGS.ROHS
Model Number: YK5050G02

Payment & Shipping Terms:

Minimum Order Quantity: 6K
Price: Please inquiry
Packaging Details: 1000pcs/Reel our product package size is 25x23CM, and is the use of aluminum vacuum packaging. And different types of containers, small cartons can be installed about 100K products. Large box can hold about 500K.
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Contact Now
Detailed Product Description
Type: SMD LED Chip Material: InGaN
Emitting Color: Green Luminous Intensity: Customers' Requirements
Luminous Flux(lm): 15-20LM Power: 0.2W
Viewing Angle(°): 120 Degree Color Rendering Index: Null
Color Temperature: 520-525nm Operating Temperature: -20 - 85
Chip Brand: Epistar Chip, Sanan Chip,Epileds Chip Current: 60mA
Voltage: 3.0-3.4V Warranty: 2 Years
Lifespan: 50000-100000H

0.2w green 520-525nm smd 5050 led chip with LM80/ROHS certification China factory for led strips





Features:

The LED are available with different color

Utilizing advanved technology

High brightness,long life

Advantages:

High-intensity

uniform illumination

,Energy-saving and environmental protection

Low-power consumption

Well consistency

Bins sorting

Full-inspection before dispatch

CE & RoHS Certification



Product Description

0.2 W Green Smd 5050 Led Chips 15 - 20 LM Luminous Flux Long Life Span

SURFACE MOUNT LED LAMPS
Product Type:YKG5050
Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Value Unit
Forward current
If
60 mA
Reverse voltage Vr 5 V
Power dissipation Pd 200 mW
Operating temperature range Top -25~+80 °C
Storage temperature range Tstg -30~+85 °C
Peak pulsing current(1/8 duty f=1KHz) Ifp 100 mA
Junction Temperature Tj 115 ℃/W
Electrostatic Discharge(HBM) ESD 1000 V
Electro-Optical characteristics (TA=25°C)



Parameter

Test

Condition



Symbol



Color

Value Unit
Min Typ Max



Color Temperature

IF=60mA CCT G -- -- -- K

Forward voltage

IF=60mA Vf G 3.0 -- 3.4 V

luminous flux

IF=60mA φ G 15 -- 20 LM

Viewing angle at 50% IV

IF=60mA 2θ1/2 G -- 120 -- Deg

Dominant wavelength

IF=60mA λd -- 520 -- 525 nm

Reverse current

Vr=5V Ir G -- 5 -- μA

Color Rendering Index

IF=60mA CRI -- -- -- -- Ra

Reel Dimensions:



Carrier Tape Dimensions:

Loaded quantity 1000 PCS Per reel.





Please read the following notes before using the product:

1. Over-current-proof

Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change (Burn out will happen).

2. Storage

2.1 Do not open moisture proof bag before the products are ready to use.

2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less.

2.3 The LEDs should be used within a year.

2.4 After opening the package, the LEDs should be kept at 30℃ or less and 70%RH or less.

2.5 The LEDs should be used within 168 hours (7 days) after opening the package.

2.6 If the moisture adsorbent material (silica gel) has fabled away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment: 60±5℃ for 24 hours.

3. Soldering Condition

3.1 Pb-free solder temperature profile.

3.2 Reflow soldering should not be done more than two times.

3.3 When soldering, do not put stress on the LEDs during heating.

3.4 After soldering, do not warp the circuit board.

4. Soldering Iron

Each terminal is to go to the tip of soldering iron temperature less than 260℃ for 5 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder.

5. Repairing

Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing.



FAQ



Q1. Can I have a sample order?



A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable .free samples will be available.



Q2: What’s the delivery time?



A: It usually takes about 5-7 days to produce an order. But the exact delivery time might be different for different orders or at different time.



Q3:What's your warranty terms?



A: The warranty for all our Led products is 2 years.



Q4: How does your factory do regarding quality control?



A: Quality is priority.We always believe Quality is our marketing and attach great importance to quality control from the very beginning to the end of the production.

Every product will be fully assembled and carefully tested before it's packed for shipment.
