Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification

China Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification supplier
Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification supplier Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification supplier Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification supplier

Large Image :  Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification

Product Details:

Place of Origin: SHENZHEN
Brand Name: Yuanke
Certification: CE.SGS.ROHS
Model Number: YKWS2812B

Payment & Shipping Terms:

Minimum Order Quantity: 10K
Price: Please inquiry
Packaging Details: 1000pcs/Reel our product package size is 25x23CM, and is the use of aluminum vacuum packaging. And different types of containers, small cartons can be installed about 100K products. Large box can hold about 500K.
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Contact Now
Detailed Product Description
Type: SMD LED Chip Material: InGaN
Emitting Color: RGB Luminous Intensity: Customers' Requirements
Luminous Flux(lm): RGB Power: 0.2W
Viewing Angle(°): 120 Degree Color Rendering Index: 20
Color Temperature: RGB Operating Temperature: -20 - 85
Chip Brand: Epistar Chip, Sanan Chip,Epileds Chip Current: 45mA
Voltage: 5V Warranty: 2 Years
Lifespan: 50000-100000H

Black White Surface Version Built-in IC Point Control 4 Pins 5050 WS2812B SK6812 RGB LED Integrated Chip


Setting Information
Item
5050 ic led ship
voltage
DC 12V
Current
60mA
light color
RGB+ic
Chip Brand
epistar
Power
0.2W
Certification
CE RoHS
Warranty
2 years
Product Description
Built In IC Point Control Surface Mount Rgb Led Ws2812b SK6812 RoHS Certification

Product Details

size:5.0*5.0*1.5mm
1.High Lumens Output & Low Brightness Decay
2.Stable Performance & Great CCT Inity.
3.Wid Color Temperature Range
4.High CRI More Than 95 available
5.good raw materials
6.Taiwan Epistar, Xianmen San'an chips

Product Material

0.2W CE RoSH DC 5V 6pin 5050 IC rgb smd led chip

1. 99.9% gold wire
2.Taiwan red copper holder good cooling
3.high brightness Sanan Epistar led chip
Original factory formal chip more stable
4.High refractive index silicone



Initial Electrical/Optical Characteristics (TA=25±5ºC)


Symbol
Item
Units
Min.
Typ.
Max.

VF
Forward Voltage
V
3.0
-
3.4
IF=60mA
IR
Reverse Current
uA
-
-
5
VR=5V
Viewing Angle
º
-
120°

IF=60mA
ø
Luminous flux
lm
65
-
70
IF=60mA
IV
Light intensity
mcd
R:500/G:1500/B:400

R:700/G:12000/B:600
IF=60mA
WLD
Dominant wavelength
nm
R:620/G:520/B:460
-
R:630/G:530/B:470
IF=60mA

Electrical / Optical characteristics0.2W CE RoSH DC 5V 6pin 5050 IC rgb smd led chip

Absolute Maximum Ratings (TA=25ºC)0.2W CE RoSH DC 5V 6pin 5050 IC rgb smd led chip
IFP Conditions : 1/10 Duty Cycle, 0.1 msec Pulse Width.

Item
Symbol
Absolute Maximum Rating
Unit
Forward Current
IF
60
mA
Pulse Forward Current
IFP
90
mA
Reverse Voltage
VR
5
V
Power Dissipation
PD
100
mW
Operating Temperature
Topr
-40ºC To +85ºC
°C
Storage Temperature
Tstg
-40ºC To +85ºC
°C
Soldering Temperature
Tsld
Reflow Soldering: 260ºC
Hand Soldering : 350ºC
for 10sec.
for 3sec.



  • Features:
  • P-LCC-4 package.
  • White package.
  • Optical indicator.
  • Colorless clear window.
  • Ideal for backlight and light pipe application.
  • Inter reflector.
  • Low current (2mA) operation.
  • Wide viewing angle.
  • Suitable for vapor-phase reflow, infrared reflow and wave solder processes.
  • Computable with automatic placement equipment.
  • Available on tape and reel (12mm Tape).
  • The product itself will remain within RoHS compliant Version.



  • Descriptions:
  • The 5050 is available in soft red, orange, yellow, green, blue and white. Due to the Package design, the LED has wide viewing angle and optimized light coupling by inter reflector, this feature makes the SMT TOP LED ideal for light pipe Application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.



  • Applications:
  • Automotive: Backlight in dashboards and switches.
  • Telecommunication: Indicator and backlight in telephone and fax.
  • Indicator and backlight for audio and video equipment.
  • Indicator and backlight in office and family equipment.
  • Flat backlight for LCD’s, switches and symbols.
  • Light pipe application.
  • General use.
