White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H

Certification
Good quality SMD 5050 LED Chips for sales
Good quality SMD 5050 LED Chips for sales
Nice product and nice service.

—— Roger park

have not tested the product yet

—— Somcha Kuzabss

This company thinks with you to get the correct LED products.

—— Allen

Thanks Mr.Huang for good support product information and fast delivery.

—— Paul George

I'm Online Chat Now

White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H

China White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H supplier
White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H supplier White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H supplier

Large Image :  White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H

Product Details:

Place of Origin: SHENZHEN
Brand Name: Yuanke
Certification: CE.SGS.ROHS
Model Number: YK5050W

Payment & Shipping Terms:

Minimum Order Quantity: 10K
Price: Please inquiry
Packaging Details: 1000pcs/Reel our product package size is 25x23CM, and is the use of aluminum vacuum packaging. And different types of containers, small cartons can be installed about 100K products. Large box can hold about 500K.
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days
Contact Now
Detailed Product Description
Type: SMD LED Chip Material: InGaN
Emitting Color: Pure White Luminous Intensity: Customers' Requirements
Luminous Flux(lm): 22-24LM Power: 0.2W
Viewing Angle(°): 120 Degree Color Rendering Index: 80
Color Temperature: 6000-6500K Operating Temperature: -20 - 85
Chip Brand: Epistar Chip, Sanan Chip,Epileds Chip Current: 60mA
Voltage: 3.0-3.4V Warranty: 2 Years
Lifespan: 50000-100000H

High quality epistar chip white 6000-6500K 60mA Datasheet 22-24LM 0.2W 5050 SMD LED Diode

5050 SMD LED PARAMETERS

TYPE COLOR CCT(k) VIEW ANGLE BRIGHTNESS(mcd) VF(Typ)
5050 BLUE SMD LED BLUE 450-470nm 120 1050MCD 3.2
5050 GREEN SMD LED GREEN 520-530nm 120 4200MCD 3.2
5050 YELLOW SMD LED YELLOW 585-595nm 120 1800MCD 2.0
5050 RED SMD LED RED 620-630nm 120 1800MCD 2.0
5050 WARM WHITE SMD LED WARM WHITE 2800-3200K 120 22-24LM 3.2
5050 Natural WHITE SMD LED WARM WHITE 4000-4500K 120 22-24LM 3.2
5050 Pure WHITE SMD LED PURE WHITE 6000-6500K 120 22-24LM 3.2
5050 COOL WHITE SMD LED PURE WHITE 8000K 120 22-24LM 3.2
5050 COOL WHITE SMD LED COOL WHITE 15000K 120 22-24LM

3.2





Specification

Setting Information
item name
5050 smd led
voltage
3.0-3.2V
current
60mA
light color
warm white/natural white/daylight white/cool white
size
5.4*5.0*1.6mm
temperature
2500k-22000k
chip
sanan epistar
working
50000 hours

Variations Available

POWER
0.2w 0.5w 1w
LUMINOUS FLUX
18-20LM ; 20-22LM; 22-24LM ;24-26LM ;50-55LM;55-60LM;60-65LM
CCT
2800-3200K;4000-4500K;5000-5500K;6000-6500K;7000-9000K;10000-11000;
CRI
70;80;90
SMD MODELS
2835;5730;3030;3014;4014;5050;3528
Product Description
White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H
SURFACE MOUNT LED LAMPS
Product Type:YKW5050W
Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Value Unit
Forward current
If
60 mA
Reverse voltage Vr 5 V
Power dissipation Pd 0.16 W
Operating temperature range Top -25~+80 °C
Storage temperature range Tstg -30~+85 °C

Peak pulsing current

(1/8 duty f=1KHz)

Ifp 90 mA



Electro-Optical characteristics (TA=25°C)


Parameter

Test

Condition



Symbol



Color

Value Unit
Min Typ Max
Color Temperature -- CCT W 6000 -- 6500 K
Forward voltage If=60mA Vf W 3.0 -- 3.4 V
luminous flux
If=60mA
φ



22



--



26



Lm



Viewing angle at 50% IV

If=60mA 1/2 W -- 120 -- Deg



Dominant wavelength

If=60mA
λd W

--



--

--



nm
Reverse current Vr=5V Ir -- -- 5 -- μA

White 6000 - 6500 K 5050 Smd Led Lumens , Epistar Led Chip 50000 - 100000 H

FAQ



Q1. Can I have a sample order?



A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable .free samples will be available.



Q2: What’s the delivery time?



A: It usually takes about 5-7 days to produce an order. But the exact delivery time might be different for different orders or at different time.



Q3:What's your warranty terms?



A: The warranty for all our Led products is 2 years.



Q4: How does your factory do regarding quality control?



A: Quality is priority.We always believe Quality is our marketing and attach great importance to quality control from the very beginning to the end of the production.

Every product will be fully assembled and carefully tested before it's packed for shipment.
